Summit - Trimless (2.79”/5.62”/8.38”/11.14”)
Material: Aluminum
Installation method: Recessed
Application: General Lighting (accent)
LED: Integrated
Length: 2.79”(71mm)/5.62”(143mm)/8.38”(213mm)/11.14”(283mm)
Height: 4.13”(105mm)
Power: 10W/15W per head
CCT：2700K/3000K/3500K/4000K/2700K-6000K
CRI: ≥90
Lumen: Up to 70lm/w
Beam angle: 8°/18°/28°/38°/50°
Dimming: TRIAC/0-10V/DALI
Adjustable: 355° Rotation | 30° Tilting
Protection class: IP20/IP65
IES File
Material: Aluminum
Installation method: Recessed
Application: General Lighting (accent)
LED: Integrated
Length: 2.79”(71mm)/5.62”(143mm)/8.38”(213mm)/11.14”(283mm)
Height: 4.13”(105mm)
Power: 10W/15W per head
CCT：2700K/3000K/3500K/4000K/2700K-6000K
CRI: ≥90
Lumen: Up to 70lm/w
Beam angle: 8°/18°/28°/38°/50°
Dimming: TRIAC/0-10V/DALI
Adjustable: 355° Rotation | 30° Tilting
Protection class: IP20/IP65
IES File
Material: Aluminum
Installation method: Recessed
Application: General Lighting (accent)
LED: Integrated
Length: 2.79”(71mm)/5.62”(143mm)/8.38”(213mm)/11.14”(283mm)
Height: 4.13”(105mm)
Power: 10W/15W per head
CCT：2700K/3000K/3500K/4000K/2700K-6000K
CRI: ≥90
Lumen: Up to 70lm/w
Beam angle: 8°/18°/28°/38°/50°
Dimming: TRIAC/0-10V/DALI
Adjustable: 355° Rotation | 30° Tilting
Protection class: IP20/IP65
IES File
